1、Product Usage
Offset water, ink by printing rollers to complete.
2、Product Structure
The group Rainbow, Hao Wang, China Eastern, China Tian, Heidelberg HEIDELBERG, E600X, Guanhua and other well-known brands offset press, printing rollers coated, and to sample the new do.
3、Features
1) hardness index hardness standard: SH25 hardness change: SH5 Note: If changes beyond the scope of this hardness may cause printing failure, and, cot also more difficult to maintain recovery.
2) diameter index change in diameter: 4% Note: If a change exceeds this diameter, need to be replaced as soon as possible.
3) Surface roughness resistant, glazed surface treatment is better, pay attention to: the timely cleaning, maintenance roller, can reduce the surface roughness of the changes.
Dongguan Da Ling Shan Xiong Hao Cots factory in Da Ling Shan Yeung Uk third industrial zone, our factory is set research and development. Production. Sale. Sale as one of the private high-tech enterprises, with the domestic advanced level of CNC lathe grinder. Banburying machine. balancing machines. long lathe detection equipment, such as several medium-sized manufacturing equipment. to ensure a strong market supply capacity and excellent product quality. of the German Japan. US-Thailand, Vietnam and other imported raw materials. unique formulation process ensure product quality has been in the lead. Cots, silicone roll, polyurethane rubber roller, roller natural rubber, nitrile rubber roller, EPDM rubber roller, rubber roller Long altitude and other professional production and processing company, has a complete and scientific quality management system. Integrity, strength and quality of Dongguan Da Ling Shan Xiong Hao Cots plant recognized by the industry. Welcome friends to visit, guidance and business negotiation.
4、Various rubber materials Cots:
|
Rubber |
Hardness |
Advantage |
Scope |
|
Nitrile rubber roller（NBR） |
13—100 |
Good oil resistance, abrasion resistance, excellent heat resistance (130 ℃), ozone resistance |
Printing rollers, conveyor rollers, textile, leather, rubber roller, printing and dyeing |
|
Polyurethane Rollers（PUR） |
10—100 |
High mechanical strength, very excellent abrasion resistance, oil resistance, air tightness |
Color steel roller, tension roller, various industrial rubber roller |
|
EPDM rubber roller（EPMD） |
40--100 |
Excellent aging resistance (no cracking rubber), good electrical insulation, chemical resistance, excellent water, hot water, steam performance |
UV printing, leather industry, qi floor coating, coating, etc. |
|
Fluorine rubber cot（FKM） |
50--85 |
Extremely excellent high temperature resistance, aging, oil, corrosion resistance, weatherability, ozone resistance, high tensile strength and hardness, from the fire self-extinguishing |
Cots and high temperature corrosion, molded products |
|
Silicone roll（Q） |
20--90 |
Excellent resistance to high and low temperature performance (-100 ℃ ~ 300 ℃), ozone resistance, aging resistance, oxygen aging, light aging, weathering resistance, electrical insulation is good, tasteless, non-toxic, anti-sticking, sticky |
Cast film, thermal transfer cot, hot rolls, sticky roller, and other uses of rubber rollers |
|
SBR roller（SBR） |
20--99 |
Heat aging resistance, wear resistance, good wet skid resistance |
Transport rollers, and other uses of rubber rollers |
|
Haipa Long Cots（CSM） |
35--99 |
Anti-aging, ozone resistance, weather resistance, chemical resistance, abrasion resistance is good, smooth non-stick rollers (hot rolled) |
Pickling line backing roll, heat resistance, corrosion Cots |
|
Neoprene rollers（CR） |
40--90 |
Good flame resistance, mechanical energy, good heat (90 ℃ ~ 110 ℃), ozone resistance, excellent weathering performance, |
Backing roll, backing roll |
5、Cots variety of purposes:
|
Name |
Performance requirements |
Use Industry |
Applicable Glue |
|
Backing roll |
Wear, acid, pressure |
Color-coated steel, stainless steel, aluminum plate pickling line |
Haipa Long (CSM), chloroprene rubber, nitrile rubber |
|
Printing roll |
Oil resistance, abrasion resistance, extraction |
Gravure printing, color printing, transfer |
Nitrile rubber, neoprene |
|
Printing rollers |
Acid, pressure, temperature |
Printing and dyeing |
Nitrile rubber, neoprene |
|
Adhesive roll |
Solvent resistance, abrasion resistance, flexibility |
Wood flooring and other industries |
Press the ink used to select types of plastic glue |
|
Pressure laminate rollers |
Temperature, pressure |
Printing processes |
EPDM, nitrile |
|
Polishing rollers |
Solvent resistance, good flexibility, without deformation |
Printing, Printing |
Press to select the types of plastic used in coatings |
|
Calender rolls |
Temperature, high hardness |
Printing processes |
Special glue |
|
Sponge roller |
Good elasticity |
Wood, steel mills suction roll |
Select by conditions |
|
Conveying rollers |
Wear |
All sectors |
As required |
|
UV printing roll |
UV-resistant oil |
Printing, wood |
Special glue |
|
Hot laminating roller |
Temperature |
Hot film |
Silicone Rubber |
6、Cots various properties
|
Species |
Suitable for rubber |
|
Wear rubber roller |
Polyurethane rubber roller, Haipa Long Cot. |
|
Cots acid |
Haipa Long Cots |
|
Oil Roller |
Nitrile rubber roller, fluorine rubber cot |
|
Solvent Cots |
EPDM rubber roller |
|
High temperature plastic rollers |
Silicone roll, fluorine rubber cot |
|
Cots and high pressure |
EPDM rubber roller |
7、Cots industries
|
Industry |
Cots species |
适用橡胶 |
|
Wood flooring processing |
Adhesive roll, sanding roller conveyor roller |
Nitrile, EPDM, natural rubber |
|
|
Printing rollers, polishing rollers, Printing rollers, |
Nitrile, polyurethane, EPDM |
|
Color-coated steel, stainless steel, aluminum composite panel production |
Tension roller, roller, backing roll, glue (cloth) roll |
Haipa Long, neoprene, polyurethane, nitrile |
|
Papermaking |
Backing roll, drying rollers, conveyor rollers |
Natural rubber, nitrile rubber |
|
Leather, artificial leather, printing and dyeing |
Adhesive roll, backing roll |
EPDM, nitrile, polyurethane |
